Zambelli

Standing-seam roofing RIB-ROOF Speed 500 profiled sheet, steel

500163 · Roof systems · Made to order

Ref. 500163

Quantity

The RIB-ROOF Speed 500 profiled sheet, 500 mm wide with a rib height of 65 mm (distinctive trapezoidal rib), is laid on concealed sliding clips without through-holes in the roof. Steel sheets are the most economical version of the system: AZ185 aluminium-zinc coating or galvanised steel with polyester/PVDF coating in RAL colours. Sheets are made to the size of the project and suit roofs from 1.5° and facades.

Specifications

Brand
Zambelli, Германия
SKU
500163
Manufacturer
Zambelli RIB-ROOF (Germany)
System
RIB-ROOF Speed 500
Type
standing-seam profiled sheet with sliding seam
Installed (cover) width
500 mm; also 333 / 400 mm, special up to 600 mm
Rib height
65 mm
Min. roof pitch
1,5°
Sheet length
up to 33 m (longer — on-site profiling)
Sheet shapes
straight, tapered, curved (convex/concave), tapered-curved
Fastening
sliding clips without perforating the roofing
Certification (steel, aluminium)
ETA-18/0034, ETA-18/0035 (CE)
Material and thickness — article number
aluminium-zinc coated steel AZ185 0.63 mm — 500163; galvanised steel, polyester 25 µm (face), protective lacquer (reverse) 0.63 mm — 500263; galvanised steel, PVDF 25 µm (face), protective lacquer (reverse) 0.63 mm — 500363
Steel
S320GD / S350GD (EN 10346)
Weight, kg/m²
6.81 (AZ) / 6.76 (coated)
Colours
RAL 3009 oxide red, RAL 7016 anthracite grey, RAL 7037 dust grey, RAL 8004 copper brown, RAL 8014 sepia, RAL 8023 orange brown, RAL 9006 white aluminium, RAL 9007 grey aluminium, RAL 9010 pure white; other RAL colours to project requirements
Options
anti-condensation fleece (up to 900 g/m²), acoustic fleece (−6 dB rain noise), tapered and curved rolling, on-site profiling
